Encrypted Advertisements

Support for additional sensors can be requested by opening an issue.

Check the Senor Request page on how to provide useful information for adding new sensors.

NOTE: Properties with a * have additional information in the device notes.

Advertisements for these devices are encrypted, therefore you need to set the key in your configuration, see for instructions the encryption_key option

BTHome DIY-sensors

BTHome sensors

binary

door

light

lock

motion

opening

smoke

switch

battery

CO2

conductivity

count

dew point

energy

humidity

illuminance

weight

moisture

PM2.5

PM10

power

pressure

rssi

temperature

TVOC

voltage

weight

binary

opening

switch

Encrypted Advertisements: Optional (16 byte bindkey)

Notes:

BTHome is a BLE format for DIY sensors. BLE monitor supports both V1 and V2 and we support most measurement types, but not all yet. If you miss one of the measurement types, please let us know, such that we can add it. More information about the format can be found on BTHome website
BTHome is supported on some Xiaomi and Qingping sensors with custom ATC pvvx firmware (select BTHome as advertising format) and on b-parasite sensors.
Multiple measurements of the same type is not supported yet in BLE monitor. Please use the official BTHome integration in HA instead.

HolyIOT HolyIOT BLE sensors

BLE sensors

battery

rssi

temperature

humidity

pressure

button *

vibration

Encrypted Advertisements: true

Notes:

button press types are ‘toggle’ or ‘no press’
Supported measurement types depend on the model.
After each button press, the sensor state shows ‘Toggle’. It will return to no press after the time set with the reset_timer option.

Linptech HS1BB(MI)

Linptech Motion Sensor

illuminance *

motion *

battery

rssi

Encrypted Advertisements: See Notes
Broadcast Rate: See Notes

Notes:

illuminance is measured in lux.
motion Motion state is ‘motion detected’ or ‘clear’.
- Illuminance is broadcasted upon every 10 minutes and when motion is detected. Motion state is broadcasted when motion is detected. Additionally, motion clear messages are broadcasted at 1, 2, 5, 10, 20 and 30 minutes after the last motion. - You can use the reset_timer option if you want to use a different time to set the sensor to motion clear.

Linptech K9B

Switch (one button version)

one btn switch *

button switch

rssi

Encrypted Advertisements: Probably (not confirmed yet)

Notes:

one btn switch returns ‘short press’, ‘double press’ or ‘long press’
There are three different versions of this switch, with one, two or three buttons.
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Linptech K9B

Switch (two button version)

two btn switch left *

two btn switch right *

button switch

rssi

Encrypted Advertisements: Probably (not confirmed yet)

Notes:

two btn switch left returns ‘short press’, ‘double press’ or ‘long press’
two btn switch right returns ‘short press’, ‘double press’ or ‘long press’
There are three different versions of this switch, with one, two or three buttons.
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Linptech K9B

Switch (three button version)

three btn switch left *

three btn switch middle *

three btn switch right *

button switch

rssi

Encrypted Advertisements: Probably (not confirmed yet)

Notes:

three btn switch left returns ‘short press’, ‘double press’ or ‘long press’
three btn switch middle returns ‘short press’, ‘double press’ or ‘long press’
three btn switch right returns ‘short press’, ‘double press’ or ‘long press’
There are three different versions of this switch, with one, two or three buttons.
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Linptech K9BB

Switch (one button version, battery powered)

one btn switch *

button switch

battery

rssi

Encrypted Advertisements: Probably (not confirmed yet)

Notes:

one btn switch returns ‘short press’, ‘double press’ or ‘long press’
This is the battery powered version of the Linptech K9B.
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Linptech KS1

Smart Wireless Switch KS1

four btn switch 1 *

four btn switch 2 *

four btn switch 3 *

four btn switch 4 *

battery

rssi

Encrypted Advertisements: Probably (not confirmed yet)

Notes:

four btn switch 1 returns ‘short press’, ‘double press’ or ‘long press’
four btn switch 2 returns ‘short press’, ‘double press’ or ‘long press’
four btn switch 3 returns ‘short press’, ‘double press’ or ‘long press’
four btn switch 4 returns ‘short press’, ‘double press’ or ‘long press’
There are two different versions of this switch, without temperature/humidity (KS1) and with temperature/humidity (KS1).
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Linptech KS1BP

Smart Wireless Switch KS1 Pro

temperature

humidity

four btn switch 1 *

four btn switch 2 *

four btn switch 3 *

four btn switch 4 *

battery

rssi

Encrypted Advertisements: Probably (not confirmed yet)

Notes:

four btn switch 1 returns ‘short press’, ‘double press’ or ‘long press’
four btn switch 2 returns ‘short press’, ‘double press’ or ‘long press’
four btn switch 3 returns ‘short press’, ‘double press’ or ‘long press’
four btn switch 4 returns ‘short press’, ‘double press’ or ‘long press’
There are two different versions of this switch, without temperature/humidity (KS1) and with temperature/humidity (KS1BP).
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Linptech MS1BB(MI)

Linptech Door and Window Sensor

opening

battery

status *

button

rssi

Encrypted Advertisements: true
Broadcast Rate: 20-25 advertisements per second

Notes:

status The opening entity has an extra attribute “status”, which can have the following values:
- window/door broken open
- door not closed

Linptech PS1BB

Linptech Pressure Sensor

reset

battery

pressure state

pressure present duration

pressure not present duration

pressure present time set

pressure not present time set

rssi

Encrypted Advertisements: true

Linptech RS1BB

Water Immersion and Rainwater sensor

moisture detected

rssi

Encrypted Advertisements: true

Petoneer SU001-T

Petoneer Smart Odor Eliminator Pro SU001-T

switch

motion

battery

rssi

Encrypted Advertisements: true

Qingping CGC1

Bluetooth alarm clock

temperature

humidity

battery *

rssi

Encrypted Advertisements: Yes (Xiaomi MiBeacon advertisement)

Notes:

battery For battery level, we do not have accurate periodicity information yet.
The sensor sends BLE advertisements in Xiaomi MiBeacon format and Qingping format, but only MiBeacon format is supported currently.
Xiaomi MiBeacon advertisements are most likely encrypted.
If you have information about update frequency, encryption key requirement, and/or a log with report_unknown: 'qingping', we can improve the documentation and implement qingping format support without encryption. Please open an issue with this information.

Qingping CGD1

Cleargrass CGD1 alarm clock

temperature

humidity

battery *

rssi

Segment LCD

Encrypted Advertisements: Yes (Xiaomi MiBeacon advertisement)
Broadcast Rate: ~1/10min.

Notes:

battery For battery level, we do not have accurate periodicity information yet.
The sensor sends BLE advertisements in Xiaomi MiBeacon format and Qingping format.
Xiaomi MiBeacon advertisements are most likely encrypted.
Qingping advertisements are not encrypted.

Qingping CGDK2

Temp & RH Monitor Lite

temperature

humidity

battery

voltage

rssi

Round body, E-Ink

Encrypted Advertisements

true

Broadcast Rate

~1/10min.

custom firmware

pvvx

Notes:

Custom firmware broadcast temperature, humidity, battery voltage and battery level in percent. Broadcast interval can be set by the user and encryption can be used as an option.

Qingping CGG1-M

Hygro thermometer

temperature

humidity

battery

voltage *

rssi

Round body, E-Ink

Encrypted Advertisements

true

Broadcast Rate

~20/min.

custom firmware

pvvx

Notes:

voltage Battery voltage is only available with custom firmware.
There are three versions of the CGG1. The CGG1-M has a qingping logo at the back (left picture)
broadcasts about 20 readings per minute, although exceptions have been reported with 1 reading per 10 minutes.
Custom firmware broadcast temperature, humidity, battery voltage and battery level in percent. Broadcast interval can be set by the user and encryption can be used as an option.

Qingping CGH1

Window Door/Sensor

opening

battery *

status *

rssi

Encrypted Advertisements: true

Notes:

battery For battery level, we do not have accurate periodicity information yet.
status The opening entity has an extra attribute “status”, which can have the following values:
- opened
- closed
- closing timeout
- device reset

Qingping CGPR1

Motion and ambient light sensor

illuminance *

light *

motion *

battery

rssi

Encrypted Advertisements: See Notes
Broadcast Rate: See Notes

Notes:

illuminance is measured in lux.
light Qingping advertisements send a message with light status (dark/light). For Xiaomi MiBeacon advertisements, 100 lux is assumed to be the limit for dark/light.
motion Motion state is ‘motion detected’ or ‘clear’.
- This sensor sends advertisements in Xiaomi MiBeacon format when connected to MiHome. In this case, communication is encrypted, so it requires an encryption key to be set in the configuration options. If it is not connected to MiHome, it will broadcast advertisements in Qingping format. This advertisement format is not encrypted, so it won’t require an encryption key. - Switching to Qingping mode is done by pressing the button for a very long time until the LED stops flashing. - In Xiaomi MiBeacon mode, illuminance is broadcasted upon every 10 minutes and when motion is detected. Motion state is broadcasted when motion is detected. Additionally, motion clear messages are broadcasted at 1, 2, 5, 10, 20 and 30 minutes after the last motion. - In Qingping mode, broadcast rate of illumination and battery is every second. - You can use the reset_timer option if you want to use a different time to set the sensor to motion clear.

Xiaomi LYWSD02MMC

Temperature and Humidity Monitor Clock

temperature

humidity

battery

rssi

Rectangular body, E-Ink

Encrypted Advertisements: true

Xiaomi LYWSD03MMC

Hygro thermometer

temperature

humidity

battery

voltage *

switch *

opening *

rssi

Small square body, segment LCD

Encrypted Advertisements

Yes (original firmware), optional with pvvx firmware

Broadcast Rate

1/10min. (battery level ~1/hr.)*

custom firmware

pvvx
ATC1441

Notes:

voltage battery voltage is only available with custom firmware
switch The switch sensor is only available with custom firmware (pvvx) and is disabled by default. It represents the state of the Reed Switch. You can enable the switch sensor by going to configuration, integrations, select devices on the BLE monitor integration tile and select your device. Click on the +1 disabled entity to show the disabled sensor and select the disabled entity. Finally, click on Enable entity to enable it. This switch sensor can be used for a temperature or humidity trigger, for use as hygrostat or thermostat (depending on settings). More information can be found here on the pvvx website
opening The opening sensor is only available with custom firmware and is disabled by default. You can enable the opening sensor by going to configuration, integrations, select devices on the BLE monitor integration tile and select your device. Click on the +1 disabled entity to show the disabled sensor and select the disabled entity. Finally, click on Enable entity to enable it. More information about the use of this opening sensor can be found on here on the pvvx website
Both custom firmwares broadcast temperature, humidity, battery voltage and battery level in percent. Broadcast interval can be set by the user and encryption can be used as an option. BLE monitor supports all possible broadcast types that can be selected in the TelinkMiFlasher tool.

Xiaomi MCCGQ02HL

Mijia Window/Door Sensor 2

battery

opening

light

status *

rssi

Encrypted Advertisements: true
Broadcast Rate: battery level ~1/day

Notes:

status The opening entity has an extra attribute “status”, which can have the following values:
- opened
- closed
- closing timeout
- device reset

Xiaomi MJWSD05MMC

Mijia Smart Temperature and Humidity Monitor 3

temperature

humidity

battery

rssi

Rectangular body, E-Ink

Encrypted Advertisements: true

Xiaomi MJYD02YL

Motion Activated Night Light

battery

motion

light

rssi

Encrypted Advertisements: true
Broadcast Rate: See Notes

Notes:

Light state is broadcasted once every 5 minutes when no motion is detected, when motion is detected the sensor also broadcasts the light state. Motion state is broadcasted when motion is detected, but is also broadcasted once per 5 minutes. If this message is within 30 seconds after motion, it’s broadcasting motion detected, if it’s after 30 seconds, it’s broadcasting motion clear. Additionally, motion clear messages are broadcasted at 2, 5, 10, 20 and 30 minutes after the last motion.
You can use the reset_timer option if you want to use a different time to set the sensor to motion clear.
Battery is broadcasted once every 5 minutes.

Xiaomi MJZNMSQ01YD

Xiaomi Door Lock Youth Edition

fingerprint *

lock *

battery

result *

key id *

action *

method *

error *

timestamp *

rssi

Encrypted Advertisements: Yes, see notes

Notes:

fingerprint The fingerprint sensor is On if the fingerprint scan was successful, otherwise it is Off The fingerprint entity has two extra attributes, result and key id.
result result shows the result of the last fingerprint reading and can have the following values:
- match successful
- match failed
- timeout
- low quality (too light, fuzzy)
- insufficient area
- skin is too dry
- skin is too wet
key id key id is an id number. For the fingerprint sensor, it can also be administrator or unknown operator
lock The state of the lock depends on the last action. The lock entity has five extra attributes, action, method, error and key id and timestamp
action action shows the last change in of the lock and can have the following values:
- unlock outside the door
- lock
- turn on anti-lock
- turn off anti-lock
- unlock inside the door
- lock inside the door
- turn on child lock
- turn off child lock
- lock outside the door
- abnormal
method method shows the last used locking mechanism and can have the following values:
- unlock outside the door
- lock
- bluetooth
- password
- biometrics
- key
- turntable
- nfc
- one-time password
- two-step verification
- Homekit
- coercion
- manual
- automatic
- abnormal
error The error state of the lock
timestamp The timestamp of the latest lock change
At the moment you can only get the encryption key with method 4 (intercepting the MiHome application traffic) as described in the FAQ. Search for /device/blelockbind or /v2/device/ble_secure_bind endpoint. Method 3 (MiHome mod) is currently being worked on and will support extracting the encryption key for this device in the next release of MiHome mod. For further information, see this issue

Xiaomi PTX

BLE wireless switch

one btn switch *

battery

rssi

Encrypted Advertisements: true

Notes:

one btn switch returns ‘single press’, ‘double press’ or ‘long press’
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Xiaomi RTCGQ02LM

Mi Motion Sensor 2

light

motion *

button *

battery

rssi

Encrypted Advertisements: true
Broadcast Rate: See notes

Notes:

motion Light state is broadcasted upon a change in light in the room and is also broadcasted at the same time as motion is detected. The sensor does not broadcast motion clear advertisements. It is therefore required to use the reset_timer option with a value that is not 0.
button The sensor also broadcasts single press if you press the button. After each button press, the sensor state shortly shows single press and will return to no press after 1 second. The sensor has an attribute which shows the last button press. You can use the state change event to trigger an automation in Home Assistant. Battery is broadcasted once every few hours.

Xiaomi SJWS01LM

Smart Water Leak Sensor

moisture detected

button

battery

rssi

Encrypted Advertisements: true

Xiaomi T700

Mi Electric Toothbrush T700

toothbrush *

battery

score *

rssi

Encrypted Advertisements: true

Notes:

toothbrush The toothbrush sensor has one attribute score
counter After starting the toothbrush, the counter will count the time you used your toothbrush
score After finishing toothbrushing, the toothbrush will report a score

Xiaomi XMMF01JQD

Smart Mijia Magic Cube

button *

rssi

Encrypted Advertisements: true

Notes:

button Possible states are ‘left’ and ‘right’, corresponding to the direction you rotate the cube. No edge information is available, only the direction, as this edge info is only available after connecting to the cube. This is not supported in BLE monitor.
After each rotation, the sensor state shows the direction. It will return to no press after the time set with the reset_timer option (default = 35 seconds).
The sensor has an attribute which shows the last button press. You can use the state change event to trigger an automation in Home Assistant.

Xiaomi XMPIRO2SXS

Xiaomi Human Body Sensor 2S

illuminance *

motion *

battery

rssi

Encrypted Advertisements: true

Notes:

illuminance is measured in lux.
motion Motion state is ‘motion detected’ or ‘clear’.
- You can use the reset_timer option if you want to use a different time to set the sensor to motion clear.

Xiaomi XMWSDJ04MMC

Electronic Thermometer and Hygrometer

temperature

humidity

battery

rssi

Small square body, EInk version

Encrypted Advertisements: true
Broadcast Rate: Once in 5 minutes.

Xiaomi XMWXKG01LM

Mijia wireless switch

one btn switch *

battery

rssi

round switch

Encrypted Advertisements: true

Notes:

one btn switch returns ‘single press’, ‘double press’ or ‘long press’
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Xiaomi XMWXKG01YL

Smart Switch (two button version)

two btn switch left *

two btn switch right *

rssi

Encrypted Advertisements: Probably (not confirmed yet)

Notes:

two btn switch left returns ‘short press’, ‘double press’ or ‘long press’
two btn switch right returns ‘short press’, ‘double press’ or ‘long press’
The switch sensor state will return to no press after the time set with the reset_timer option. It is advised to change the reset time to 1 second (default = 35 seconds).

Xiaomi XMZNMS08LM

Smart Door Lock 1S

battery

door *

lock *

key id *

action *

door action *

method *

error *

timestamp *

rssi

Encrypted Advertisements: true
Broadcast Rate: Battery state can take up to several hours before it is updated.

Notes:

lock The state of the lock depends on the last action. The lock entity has five extra attributes, action, method, error and key id and timestamp
action action shows the last change of the lock (displayed as an attribute of the lock sensor) and can have the following values:
- unlock outside the door
- lock
- turn on anti-lock
- turn off anti-lock
- unlock inside the door
- lock inside the door
- turn on child lock
- turn off child lock
- lock outside the door
method method shows the last used locking mechanism (displayed as an attribute of the lock sensor) and can have the following values:
- unlock outside the door
- lock
- bluetooth
- password
- biometrics
- key
- turntable
- nfc
- one-time password
- two-step verification
- Homekit
- coercion
- manual
- automatic
- abnormal
error The error state of the lock (displayed as an attribute of the lock sensor)
key id key id is an id number, displayed as an attribute of the lock sensor).
timestamp The timestamp of the latest lock change (displayed as an attribute of the lock sensor)
door The door entity has one extra attributes door action.
door action door action shows the last change in of the door state (displayed as an attribute of the door sensor) and can have the following values:
- open the door
- close the door
- timeout, not closed
- knock on the door
- pry the door
- door stuck

Xiaomi Lockin DSL-C08

Lockin Q2

lock *

key id *

action *

method *

error *

armed away *

timestamp *

battery

rssi

Encrypted Advertisements: Yes, see notes

Notes:

lock The state of the lock depends on the last action. The lock entity has five extra attributes, action, method, error and key id and timestamp
key id key id is an id number. For the fingerprint sensor, it can also be administrator or unknown operator
action action shows the last change in of the lock and can have the following values:
- unlock outside the door
- lock
- turn on anti-lock
- turn off anti-lock
- unlock inside the door
- lock inside the door
- turn on child lock
- turn off child lock
- lock outside the door
- abnormal
method method shows the last used locking mechanism and can have the following values:
- unlock outside the door
- lock
- bluetooth
- password
- biometrics
- key
- turntable
- nfc
- one-time password
- two-step verification
- Homekit
- coercion
- manual
- automatic
- abnormal
error The error state of the lock
timestamp The timestamp of the latest lock change
armed away armed away Inside the locked device, this event is output from the door ‘up’ handle.
Only supports the Bluetooth version (MiHome version)

Xiaomi/MiaoMiaoCe MHO-C401

Alarm clock

temperature

humidity

battery

voltage

rssi

Small square body, E-Ink display

Encrypted Advertisements

true

Broadcast Rate

1/10min. (battery level 1/hr.)

custom firmware

pvvx

Notes:

Custom firmware’s broadcast temperature, humidity, battery voltage and battery level in percent. Broadcast interval can be set by the user and encryption can be used as an option. BLE monitor will automatically use the advertisement type with the highest accuracy, when setting the firmware to broadcast all advertisement types.

Yeelight YLAI003

Smart Wireless Switch

button *

battery

rssi

Encrypted Advertisements: true

Notes:

button press types are ‘single press’, ‘double press’ or ‘long press’
After each button press, the sensor state shows the type of press. It will return to no press after the time set with the reset_timer option.
It is advised to change the reset time to 1 second (default = 35 seconds).
The sensor has an attribute which shows the last button press. You can use the state change event to trigger an automation in Home Assistant.

Yeelight YLKG07YL_YLKG08YL

Rotating Dimmer

dimmer *

rssi

Encrypted Advertisements: true

Notes:

dimmer types are ‘rotate’, ‘rotate (presses)’, ‘short press*’, ‘long press’. For rotation, it reports the rotation direction (left, right) and how far you rotate (number of steps). For short press it reports how many times you pressed the dimmer. For long press it reports the time (in seconds) you pressed the dimmer.
The dimmer sensor state will return to no press after the time set with the reset_timer option
It is advised to change the reset time to 1 second (default = 35 seconds).

Yeelight YLYB01YL-BHFRC

Bathroom Heater Remote Control

bathroom heater remote *

button *

rssi

Encrypted Advertisements: Partly

Notes:

bathroom heater remote button pressed options are ‘heat’, ‘air exchange’, ‘dry’, ‘fan’, ‘swing’, ‘speed -‘, ‘speed +’, ‘stop’ or ‘light toggle’
button press types are ‘short press’ or ‘long press’
The state of the remote sensor shows the remote button being pressed, the attributes shows the type of press.
It will return to ‘no press’ after the time set with the reset_timer option.
It is advised to change the reset time to 1 second (default = 35 seconds).

Yeelight YLYK01YL

Remote Control

remote *

remote single press

remote long press

rssi

Encrypted Advertisements: Partly

Notes:

remote button pressed options are ‘on’, ‘off’, ‘color temperature’, ‘+’, ‘M’, ‘-‘
The state of the remote sensor shows the combination of both, the attributes shows the button being used and the type of press individually.
It will return to ‘no press’ after the time set with the reset_timer option.
It is advised to change the reset time to 1 second (default = 35 seconds).
Additionally, two binary sensors are generated (one for ‘short press’, one for ‘long press’), which is ‘True’ when pressing ‘on’, ‘+’ or ‘-‘ and ‘False’ when pressing ‘off’.

Yeelight YLYK01YL-FANCL

Fan Remote Control

fan remote *

button *

rssi

Encrypted Advertisements: Partly

Notes:

fan remote button pressed options are ‘fan toggle’, ‘light toggle’, ‘wind speed’, ‘wind mode’, ‘brightness’, ‘color temperature’
button press types are ‘short press’ or ‘long press’
The state of the remote sensor shows the combination of both, the attributes shows the button being used and the type of press individually.
It will return to ‘no press’ after the time set with the reset_timer option.
It is advised to change the reset time to 1 second (default = 35 seconds)

Yeelight YLYK01YL-VENFAN

Ventilator Fan Remote Control

ventilator fan remote *

button *

rssi

Encrypted Advertisements: Partly

Notes:

ventilator fan remote button pressed options are ‘swing’, ‘power toggle’, ‘timer 30 minutes’, ‘timer 60 seconds’, ‘strong wind speed’, ‘low wind speed’
button press types are ‘short press’ or ‘long press’
The state of the remote sensor shows the combination of both, the attributes shows the button being used and the type of press individually.
It will return to ‘no press’ after the time set with the reset_timer option.
It is advised to change the reset time to 1 second (default = 35 seconds).

Encrypted Advertisements

Table of contents
